Removable apron angle and insert permit 1/4" reverse bends in lighter material;
Other adjustment features
• Leveling screws and lock nuts on pedestals
• Jack screws and tensioner bolts on the apron
• Truss rods on the apron, base and upper beam
• Replaceable nose bar and apron inserts
Maximum Lift of Beam...................................................... 2 1/4”
Front to Rear Beam Adjustment........................................1 3/8”
Minimum Reverse Bend...................................................... 1/4”
Minimum Flange in Capacity Material.................................... 1”
8’ MODELS: Bending Length............................................. 97”
FH816
Maximum Capacity, Mild Steel........................................... 16 ga
Cap w/bending support, angle removed, mild steel............ 20 ga
Dimensions.......................................................... 140” x 52” x 60”
Shipping Weight............................................................. 1,650 lbs
FH818
Maximum Capacity, Mild Steel.......................................... 18 ga
Cap w/bending support, angle removed, mild steel........... 22 ga
Dimensions................................................... 138” x 48” x 59 1/2”
Shipping Weight........................................................... 1,300 lbs
10’ MODELS: Bending Length........................................ 121”
FH1016
Maximum Capacity, Mild Steel.......................................... 16 ga
Cap w/bending support, angle removed, mild steel........... 20 ga
Dimensions......................................................... 161” x 53” x 60”
Shipping Weight............................................................ 2,675 lbs
FH1018
Maximum Capacity, Mild Steel.......................................... 18 ga
Cap w/bending support, angle removed, mild steel.......... 22 ga
Dimensions........................................................ 159” x 52” x 60”
Shipping Weight........................................................... 2,200 lbs
