New Equipment
Central States Machinery is fully committed to ensuring your machinery needs are met. Our product line encompasses Fabrication, HVAC, Precision Machinery, and Metal Processing Systems. From start to finish, customer service is our TOP PRIORITY. Our knowledgeable sales force guides you through the sales process. Experienced and professional technicians train you and your staff on site. All are available to support you long after the sale.
Bending Length....................................................................48"
Finger Widths............................................................2", 3", 4"
U-416
Cap Mild Steel, 1” Flange, (Bar & Angle in Place)..........16 ga
Minimum Reverse Bend (Bar & Angle Removed)..............1/4"
Maximum Lift of Beam....................................................1-1/4"
Maximum Depth of Box........................................................4"
Front to Rear Adjustment...................................................5/8"
Shipping Weight............................................................495lbs
U-422
Cap Mild Steel, 1” Flange, (Bar & Angle in Place)..........22 ga
Minimum Reverse Bend (Bar & Angle Removed)............5/16"
Maximum Lift of Beam........................................................7/8"
Maximum Depth of Box.........................................................3"
Front to Rear Adjustment...................................................1/4"
Shipping Weight.............................................................280lbs
Options & Accessories
• Bench Stand
