Maximum Lift of Beam..........................................................................1 1/2”
Maximum Depth of Box..............................................................................4”
Minimum Reverse Bend..........................................................................1/4”
Minimum Flange in Capacity Material........................................................1”
Finger Widths...................................................................................2”, 3”, 4”
HBU48-12 – 4 Foot Model
Maximum Capacity, Mild Steel.............................................................12 ga
Capacity w/Bending Support Angle Removed, Mild Steel....................16 ga
Bending Length...................................................................................48 1/4"
Front to Rear Beam Adjustment...............................................................1/2”
Dimensions, Counterweights in Place.....................................72" x 36” x 53”
Shipping Weight..............................................................................1,330 lbs
HBU72-16 – 6 Foot Model
Maximum Capacity, Mild Steel.............................................................16 ga
Capacity, Stainless Steel.....................................................................20 ga
Bending Length........................................................................................72"
Front to Rear Beam Adjustment.................................................................1”
Dimensions, Counterweights in Place....................................96" x 36” x 53”
Shipping Weight..............................................................................1,700 lbs
