Punching Force.....................................................................................................................40 Tons
Material Thickness - Minimum.....................................................................................................060”
Material Thickness – Maximum...................................................................................................500”
Maximum Punch Diameter.........................................................................................................5.00”
Punching Capacity A36 (60 ksi/410 MPa Shear Strength
.250................................................................................................................................5.00” (shear)
.375..............................................................................................................................2.344” (shear)
.500..............................................................................................................................1.406” (shear)
Punching Hit Rate...................................................................................................................80HPM
10 gauge material punched on 1” centers
X-axis Processing Area..................................................................................................................80”
Y-axis Processing Area...............................................................................................................61.5”
Positioning Speed Per Axis.............................................................................................1,200 in/min
Positioning Accuracy...............................................................................................................±0.005”
Minimum Programmed Increment.............................................................................................0.001”
Maximum Blank Size – Without Positioning..........................................................................60” x 60”
Maximum Blank Size – With Auxiliary Tables and Repositioning........................................60” x 120”
Shipping Weight – Approximately....................................................................................... 28,000lbs
Foundation Requirement.......8” reinforced concrete foundation is required beneath the press frame
Electrical Requirement............................................................................................................480/3/60
