New Equipment
Central States Machinery is fully committed to ensuring your machinery needs are met. Our product line encompasses Fabrication, HVAC, Precision Machinery, and Metal Processing Systems. From start to finish, customer service is our TOP PRIORITY. Our knowledgeable sales force guides you through the sales process. Experienced and professional technicians train you and your staff on site. All are available to support you long after the sale.
B SERIES P SERIES
Estun E21 Control Dalem DAC-360 Control
Hand Wheel Blade Gap Adjust (Manual) CNC Blade Gap
Electric Rake Angle Adjust (Manual) CNC Rake Angle
Leuze Light Curtain/Photocell Leuze Light Curtain/Photocell
3 Front Sheet Supports 3 Front Sheet Supports
Backgauage AC motor w/Shaft and Chain Drive Backgauage AC Servo w/Ball Screw
Bosch (Rexroth) Hydraulics Bosch (Rexroth) Hydraulics
SERIES 1/4-10, SERIES 3/8-10, SERIES 1/2-10
Max Shearing Capacity, Mild Steel....................................................1/4",1/4",1/2"
Max Shearing Capacity, Stainless Steel..........................................1/8".1/8", 1/4"
Rake Angle...................................................................................................0.5-2°
Back Gauge Range...........................................................................................39"
Full Stroke Per Minute - No Load..............................................................12,10, 8
Hold Downs.............................................................................................12, 15,14
Motor.........10 HP/53 Gal Oil Cap, 10 HP/53 Gal Oil Cap, 30 HP/145 Gal Oil Cap
Dimensions..................................145"x 78"x 81" , 184"x 82"x 86", 157"x 90"x 93"
Shipping Weight...............................................13,900 lbs, 19,900 lbs, 23,200 lbs
SERIES 1/4-13, SERIES 3/8-13, SERIES 1/2-13
Max Shearing Capacity, Mild Steel...................................................3/8", 3/8", 1/2"
Max Shearing Capacity, Stainless Steel......................................3/16", 3/16", 1/4"
Rake Angle.....................................................................................................0.5-2°
Back Gauge Range............................................................................................39"
Full Stroke Per Minute - No Load..................................................................9, 8, 8
Hold Downs.............................................................................................13, 15, 18
Motor........20 HP/74 Gal Oil Cap, 30 HP/106 Gal Oil Cap, 40 HP/172 Gal Oil Cap
Dimensions....................................147"x 91"x 11", 188"x 91"x 95", 190"x 93"x 99"
Shipping Weight.................................................19,900 lbs, 28,700 lbs, 35,300 lbs
